Teltonika PR3PDNP0 DIN Rail Power Supply 12V 20W 1.67A

DIN Rail Power Supply 12V 20W 1.67A

DIN Rail Power Supply, DC output voltage 12V, single output power 20W, DC output current 1.67A

Please feel free to contact us about this item, and we will recommend an IT Sales and Service Provider in your area.


Resellers: for pricing and to place orders.

In stock email will be sent.
Instock notification already exists.
Order SKU: Supplier Code:

Single output power 20 W
Input voltage range 100-240 VAC 50/60 Hz
DC output voltage 12 V
DC output current 0~1.67 A
Output ripple and noise 120 mVp-p
Line regulation ±1 %
Load regulation ±1 %
Efficiency 80 %
Adjustable range for DC voltage ±1 %
Test standard EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
EN55022:2010
EN61000-3-2:2014
EN61000-3-3:2013
EN55024:2010/A1:2015
Inrush current Cold start current 20 A/ 115 VAC; 40 A/ 230 VAC
Overload protection 105 % ~ 160 % cut off the output, automatic recovery
Over voltage protection 120 % ~ 140 % shut down O/P voltage, re-power on to recover
Setup, rise, hold up time 500 ms; 30 ms/ 230 VAC at full load; 1000 ms; 30 ms/ 115 VAC at full load
Withstand voltage I/P-O/P: 1.5 kV; I/P-FG: 1.5 kV; O/P-FG: 0.5 kV 1 minute
Isolation resistance I/P-O/P I/P-FG O/P-FG: 500 VDC/ 1000 MΩ
Working temperature -10 °C ~ +50 °C
Mounting options 35 mm DIN Rail
Dimensions 22.5 x 90 x 100 mm
Weight 19 g
