ETU-LINK ESDPX-324CN10 10 GbE SFP+ to SFP+ 24AWG Passive DAC Cable, 10M

10 GbE SFP+ to SFP+ 24AWG Passive DAC Cable, 10M

Please feel free to contact us about this item, and we will recommend an IT Sales and Service Provider in your area.


Resellers: for pricing and to place orders.

In stock email will be sent.
Instock notification already exists.
Order SKU: Supplier Code:

Universal 10Gigabit SFP+ to SFP+ DAC (Direct Attached Cable)

Works with Grandstream, Sophos, Ubiquiti, Edge-Core, NETGEAR, D-Link, TP-Link, LevelOne, ZyXEL, etc.

Length 10m
30 AWG passive

The SFP+ cable assemblies are high-performance, cost effective I/O solutions for 10Gb Ethernet and 10G Fibre Channel applications. SFP+ copper modules allow hardware manufacturers to achieve high port density, configurability and utilization at a very low cost and to reduce power budget. The high-speed cable assemblies meet and exceed the performance and reliability requirements stipulated by Gigabit Ethernet and Fibre Channel industry standard.

  • Support multi-gigabit data rates up to 10.5Gbps
  • Support 1x, 2x, 4x and 8x Fiber Channel data rates
  • Hot-pluggable SFP 20PIN footprint
  • Serial ID module on MOD(0-2)
  • AC coupling of PECL signals
  • EMI/EMC performance
  • Low Power Consumption < 0.5W
  • Power Supply :+3.3V
  • Compliant to SFP+ MSA
  • Temperature Range: 0~ 70 °C
  • ROHS Compliance

Applications
Storage Area Networks( SAN), Network Attached Storage and Storage Servers
1G/2G/4G/8G Fiber Channel
Switched fabric I/O such as ultra high bandwidth switches and routers
Data center cabling infrastructure
High density connections among network equipment

Standards
Compliant with SFP MSA (INF-8074i)
