QNAP TS-H3077AFU-R5-32G 30-bay 2.5" SATA all flash NAS, 32 GB RAM, Rackmount, Dual Power
2U 30-bay 2.5" SATA all flash NAS, AMD Ryzen 5 7000 series 6C12T (boost up to 5.1 GHz), 32GB DDR5 non-ECC RAM (max. 128GB total), 2x 10GBASE-T + 2x 2.5 GbE RJ45, 3 x PCIe Gen 4 expansion slots, 2 x 550W redundant power supply
Highly reliable ZFS-based all-flash NAS with AMD Ryzen™ 7000 series processor – boosting all-round business with petabyte-scale storage and 100 GbE potential
Gain a competitive advantage by deploying an AMD Ryzen™ 7000 series-powered SATA SSD all-flash storage with 30 drive bays. The TS-h3077AFU is ideal for media production companies, enterprises, and science research institutions that require high-performance large capacity storage for storing recordings, business assets, Big Data, and virtual machines.
Optimised SSD performance
The QuTS hero operating system maximizes SSD performance and lifespan by featuring technologies such as inline data deduplication, QSAL (QNAP SSD Antiwear Leveling), and more.
2 x 10/2.5 GbE as standard and upgradable to 100 GbE
Upgrade to 100/25 GbE using a PCIe network card and accelerate virtualization, intensive file access, media file transfer, and large backup/restoration tasks.
Long-term and stable supply
The TS-h3077AFU will be available and supported by QNAP for an extended period, up to 2030.
Built-in GPU for graphics
Power-efficient AMD Radeon™ Graphics streamlines video editing/transcoding and simultaneously runs multiple tasks.
Petabyte-scale storage
Connect up to eight 24-bay JBODs (TL-R2400PES-RP) to attain petabyte-scale storage capacity of 192 drives.
DDR5 RAM
Uses industry-leading DDR5 RAM. Expandable to 192 GB for handling more tasks, and supports ECC memory.
|
CPU |
AMD Ryzen™ 5 7000 series 6-core/12-thread processor, burst up to 5.1 GHz AMD Radeon Graphics |
|
CPU Architecture |
64-bit x86 |
|
Floating Point Unit |
|
|
Encryption Engine |
(AES-NI) |
|
Hardware-accelerated Transcoding |
|
|
System Memory |
32 GB UDIMM DDR5 (1x 32 GB) |
|
Maximum Memory |
192 GB (4 x 48 GB) |
|
Memory Slot |
4 x UDIMM DDR5 |
|
Flash Memory |
5GB (Dual boot OS protection) |
|
Drive Bay |
30 x 2.5-inch SATA 6Gb/s, 3Gb/s |
|
Drive Compatibility |
2.5-inch SATA solid state drives |
|
Hot-swappable |
|
|
SSD Cache Acceleration Support |
|
|
GPU pass-through |
|
|
2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M/10M) |
|
10 Gigabit Ethernet Port |
2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
|
Wake on LAN (WOL) |
|
|
Jumbo Frame |
|
|
PCIe Slot |
3 *Slot 2 provides the width of PCIe Gen4 x8 when Slot 1 is not in use, and provides the width of PCIe Gen4 x4 when Slot 1 is in use. |
|
USB 3.2 Gen 2 (10Gbps) Port |
2 x Type-A USB 3.2 Gen 2 10Gbps |
|
Form Factor |
2U Rackmount |
|
LED Indicators |
Power Status, SSD 1-30, Status, LAN, storage expansion port status |
|
Buttons |
Power, Reset |
|
Dimensions (HxWxD) |
88.3 × 482 × 549.7 mm Excludes ear hook and the protruding part of the Power Supply Unit. |
|
Weight (Net) |
12.73 kg |
|
Weight (Gross) |
18.69 kg |
|
Operating Temperature |
0 - 40 °C (32°F - 104°F) |
|
Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
|
Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
|
Power Supply Unit |
550W(x2), 100-240V |
|
Power Consumption: Operating Mode, Typical |
380.23 W Tested with drives fully populated. |
|
Fan |
System fan: 3 x 60mm, 12VDC |
|
System Warning |
Buzzer |
|
Standard Warranty |
5 |
|
Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
5000 |
|
