QNAP QVP-21C 2-bay high-performance NVR
- Build a complete surveillance solution with affordable deployment
- Live surveillance monitoring, remote management, and smart AI
The QVP-21C QVR Pro appliance is a tower-based network surveillance server with an Intel® Celeron® quad-core processor that supports eight free IP camera channels and up to sixteen IP camera channels. Offering an economic and high-performance software and hardware integrated video surveillance solution, the QVP-21C fulfills requirements for secure, reliable, and centrally-managed video surveillance storage for small businesses and offices.
Smoother surveillance streaming with 2.5GbE connectivity
Connect the two built-in 2.5GbE ports to a QNAP 2.5GbE switch to benefit from a smoother surveillance streaming experience.
Easy remote monitoring with the QVR Pro Client mobile app
The QVR Pro Client mobile app allows you to remotely monitor multiple channels simultaneously. If your network connection is slow or metered/capped, you can choose the low-bandwidth mode to view a bandwidth-optimized stream without affecting the quality of recordings. In addition, you can remotely set the camera’s preset point or control the PTZ cameras within the app.
Supports ONVIF cameras
Compatible with thousands of cameras from over 200+ brands and ONVIF standards.
Long-term model
The QVP-21C will be available and supported by QNAP for an extended period, up to 2029.
Dual HDMI™ outputs
Play and switch between multi-channel real-time 4K videos on two monitors with extended display.
High-performance NVR
Boost your surveillance data transmission efficiency with dual-port 2.5GbE, a USB 3.2 Gen2 10Gbps port, and 8GB RAM.
RAID protection
Unlike traditional DVR and NVR, the QVP-21C protects your data from drive failure with RAID.
Lightweight AI surveillance applications
QVP-21C incorporates QNAP smart surveillance applications and supports Intel® OpenVINO™ AI engine and Edge TPU expansion via M.2 SSD slots to boost facial recognition performance in QVR Face.
QVP-21C vs. other NAS-based surveillance systems. What’s the difference?
In a conventional NAS-based surveillance system, surveillance is just one of many applications available to users. As all these applications need to share NAS system resources and storage space, surveillance performance could be impacted. The QVP-21C QVR Pro Appliance overcomes this by providing dedicated storage space and reserving full system resources for surveillance, delivering the utmost performance to fulfill professional surveillance system requirements. The QVP-21C also comes with built-in camera channel licenses and essential applications to enable local installation without requiring an internet connection. Simply install the hard drives and power up the QVP-21C to start the installation process.
High-capacity video surveillance storage solution
QVP-21C is a professional network surveillance server, compatible with 8,000+ IP cameras of 200+ brands and thousands of ONVIF network cameras.
|
|
---|---|
OS |
QVR Pro OS (QVP) |
CPU |
Intel® Celeron® J6412 4-core/4-thread processor, burst up to 2.6 GHz |
CPU Architecture |
64-bit x86 |
Graphic Processors |
Intel® UHD Graphics |
Hardware-accelerated Transcoding |
|
System Memory |
8GB |
Maximum Memory |
16 GB ( 2 x 8 GB) |
Memory Slot |
2 x SO-DIMM DDR4 |
Flash Memory |
4GB (Dual boot OS protection) |
Max Live Cameras (Local Display) |
12ch @ All 720p,H.264, 30FPS |
Max Playback Cameras (Local Display) |
12 |
Max Concurrent Connection (Client) |
8 (4 live cameras / per remote client) |
Embedded Channel |
8 |
Max Channel |
16 H264 / 1920x1080 / 30FPS |
Max Throughput |
200 Mbps |
Drive Bay |
2 x 3.5-inch SATA 6Gb/s The system is shipped without HDD. |
Drive Compatibility |
3.5-inch SATA hard disk drives |
Hot-swappable |
|
M.2 SSD Slot |
2 x M.2 2280 PCIe Gen 3 x2 |
2.5 Gigabit Ethernet Port |
2 |
USB 2.0 port |
2 |
USB 3.2 Gen 2 (10Gbps) Port |
2 |
HDMI™ Output |
2, HDMI™ 1.4b (up to 4096 x 2160 @ 30Hz) |
Form Factor |
Tower |
LED Indicators |
HDD 1-2, Status, LAN, USB port, M.2 port |
Buttons |
Power, Reset, USB Auto Copy |
Dimensions (HxWxD) |
169.2 × 102 × 220.5 mm |
Weight (Net) |
1.57 kg |
Weight (Gross) |
2.57 kg |
Operating temperature |
0 - 40 °C (32°F - 104°F) |
Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
Power Supply Unit |
60W/65W adapter, 100-240V |
Power Consumption: HDD Sleep Mode |
20.943 W |
Power Consumption: Operating Mode, Typical |
24.238 W |
Fan |
1 x 70mm, 12VDC |
Sound Level |
15.4 db(A) |
System Warning |
Buzzer |
Tray Locker |
Yes |
File System: Internal Hard Drive |
EXT4 |
RAID Recovery |
Yes |
Online RAID Capacity Expansion |
Yes |
RAID 1 |
Yes |
RAID 0 |
Yes |
JBOD |
Yes |
Single Disk |
Yes |
Wake on LAN (WOL) |
Yes |
Schedule Power On/Off (15 settings) |
Yes |
Telnet & SSH logins (Admin only) |
Yes |
Syslog Server & Client |
Yes |
|
|
---|---|
