Powershield PSG750 SafeGuard 750VA UPS, 6x 3-Pin Outlet Plugs
- 3x 3-Pin UPS Outlets with Surge Protection
- 3x 3-Pin Surge Protection Outlets
The SafeGuard 750VA /450W Line Interactive UPS provides a buffer between your equipment and inconsistent mains power supply. This cost effective, compact device constantly stands guard beside your sensitive equipment.
3 x NZ UPS and Surge Outlets, 3 x NZ Surge Only Outlets
- Automatic Voltage Regulation (Buck and Boost)
- Light-weight compact and elegantly designed
- Intelligent microprocessor control
- Monitoring and shutdown software included
- Fax/modem/LAN surge suppression port
- Overload protection and alarm
- Output short circuit protection
- Start on battery function (cold start)
- USB communication
- Easy user replaceable battery
- Australian/New Zealand approved sockets
- Wall mountable
- Fast charging – 90% in 4 hours
- 2 Year Warranty
|
SPECIFICATIONS |
|
|
Capacity |
750V A / 450W |
|
Topology |
Line Interactive |
|
INPUT |
|
|
Voltage |
230V AC (Nominal) |
|
Voltage Range |
177-290V AC |
|
Frequency Range |
50/60Hz±5Hz |
|
OUTPUT |
|
|
Output Voltage |
230V AC±10% |
|
Frequency Range |
Battery Mode 50Hz - 60Hz±1% |
|
Transfer Time |
6ms (Typical) |
|
Waveform (Battery Mode) |
Simulated Sine Wave |
|
Outlets |
3 Surge Prot. and 3 Surge Prot. & UPS |
|
BATTERY |
|
|
Battery Type & Number |
12Vx9AH |
|
Typical Recharge Time |
8 hours recovery to 90% capacity |
|
Backup Time |
25 Mins. (1 PC load at 100W) |
|
PROTECTION |
|
|
Full Protection |
Overcharge, discharge, |
|
Surge Protection |
468 Joules / 11000Amps |
|
Data Protection |
Tel / Modem / LAN, RJ45 Connector |
|
COMMUNICATIONS & MANAGEMENT |
|
|
Interface |
USB Interface |
|
Software |
NetGuard® supports Windows®, |
|
LED Alarm |
AC Mode, Battery Mode, |
|
Audible Alarm |
Battery Mode, Low Battery |
|
PHYSICAL |
|
|
Dimensions (D x W x H) |
(199 x 292 x 91)mm |
|
Net Weight |
7kg |
|
OPERATING ENVIRONMENT |
|
|
Temperature |
0 - 40°C |
|
Humidity |
0 - 90% (RH non-condensing) |
|
Noise Level |
|
|
COMPLIANCE |
|
|
Safety |
EN62040-1-1 2003. IEC60950-1 : 2001 |
|
EMC |
EN62040-2 2006 |
|
RoHS |
Directive 2011 / 65 / EU |
|
