Grandstream GWN7670 WiFi 7 Wireless AP, 3.6Gbps aggregate wireless throughput

WiFi 7 Wireless AP, 3.6Gbps aggregate wireless throughput

Please feel free to contact us about this item, and we will recommend an IT Sales and Service Provider in your area.


Resellers: for pricing and to place orders.

In stock email will be sent.
Instock notification already exists.
Order SKU: Supplier Code:

The new GWN7670 is a dual-band Wi-Fi 7 access point that allows small-to-medium businesses, retail, hospitality, and similar verticals to build next-generation Wi-Fi networks with top-of-the-line speeds, capacity, stability, and efficiency.

With support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, Bluetooth Low Energy 5.3, and more, the GWN7670 is an ideal Wi-Fi access point for wireless network deployments with medium-to-high user density.

The GWN7670 offers dual-band 2x2:2 MIMO with DL/UL OFDMA technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range. This Wi-Fi 7 access point improves bandwidth utilization and anti-interference ability with multi-RU and Preamble Puncturing technology. With 4096 QAM modulation, Wi-Fi 7 achieves a significant increase in data transfer rates. The GWN7670 also includes MLO technology to optimize spectrum resource utilization to ensure a smooth experience for every user.

To ensure easy installation and management, the GWN7670 uses a controller-less distributed network management design in which the controller is embedded within the product’s Web user interface The GWN7670 is also supported by GDMS Networking and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform. It is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi capable IP phones.

  • 3.6Gbps aggregate wireless throughput, 5Gbps aggregate wired throughput
  • Integrated Wi-Fi 7 & 2x2:2 MIMO with MLO, 4KQAM, MRU, Preamble Puncturing Technology
  • Up to 175-meter coverage range
  • Supports 256 concurrent Wi-Fi client devices
  • Advanced QoS to ensure real-time performance of low-latency applications
  • Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
  • Self-power adaptation upon auto-detection of PoE+
  • Embedded controller manages up to 50 local GWN APs; GDMS Networking offers unlimited AP management, & GWN Manager offers on-premise software AP management

Client Devices : Up to 256
2.4G Throughput : 688Mbps (2x2:2 MIMO)
5G Throughput : 2882Mbps (2x2:2 MIMO)
Range : Up to 175 Meters
Network Interfaces : 2x 2.5G Ethernet WAN/LAN
PoE/PoE+ : Supports PoE 802.3af/802.3at; Max Consumption: 14.5W
Wi-Fi Standards : IEEE 802.11 a/b/g/n/ac/ax/be
SSIDs : 32 SSIDs total, 16 per radio (2.4GHz & 5GHz)
Antennas : 5 single frequency antennas
Wi-Fi and Security Systems : WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device
Dimensions : 185mmx185mmx44.5mm
Mounting : Indoor wall mount or ceiling mount, kits included
