AKCP SP4POE SNMP Enabled Web-Based Environmental Monitoring Device, 4 ports, PoE

SNMP Enabled Web-Based Environmental Monitoring Device, 4 ports, PoE

Please feel free to contact us about this item, and we will recommend an IT Sales and Service Provider in your area.


Resellers: for pricing and to place orders.

This item is not normally held in stock. We’ll order it in on request. Please contact us for estimated delivery time
In stock email will be sent.
Instock notification already exists.
Order SKU: Supplier Code:

A High-Speed, Accurate and Intelligent Monitoring device. The sensorProbe4 is a completely embedded host with a proprietary Linux like OS which includes TCP/IP stack, a built in web-server and full Email and SNMP functionality.

Based on years of Industry Experience it’s ready to run right out of the box, simply assign the IP address and connect to the embedded web server.

The sensorProbe4 (SP4 PoE) can record all events in its database with a time stamp of when the sensor alarm was raised and the action taken place. A standalone product with no external software dependencies, the sensorProbe4 gives you the very best for your monitoring needs.

It has 4 auto-sense intelligent sensor ports which work with a wide range of AKCess Pro intelligent sensors. It can use any combination of sensors to monitor temperature, humidity, water leakage, airflow, security and even control relays.

AKCess Pro sensors can also be used to detect AC voltage and measure DC voltage. Our sensors include an integrated data collection and graphing package to spot trends in the airflow, temperature and humidity.

  • Fully embedded TCP/IP and web-server.
  • Built-in notification features – Email and SNMP traps.
  • 4 auto-sense ports for connecting any AKCess Pro sensors.
  • A new improved web-based interface for easy configuration and monitoring.
  • Continuous time feature on every sensor port to eliminate false warning alerts.
  • Login for User and Administrator for better security.
  • Battery backed time of day clock for an accurate system date and time.
  • A standalone product without any external hardware and software dependencies.
  • Micro code firmware update over the Internet.
  • Customized color configuration for displaying alerts.
  • Network Management System Integration.
  • Power Over Ethernet - IEEE 802.3af  compliant

Components
Manufactured using highly integrated, low power surface mount technology to ensure long term reliability.

Dimensions
Size 8.5″ x 5.43″ x 1.80″
1U Rack Mount Standard
Weight 1.6 Kg

Inputs
x4 RJ-45 ports for connecting AKCess Pro sensors

Operating Environment
Temperature : Min. -35° C – Max.80° C
Humidity : Min. 20% – Max. 80% (Non-Condensing)

Power Requirements
Voltage 7.5 – 9 V / >= 1.2 Amp

Network Interface
Standard 100MB Full Duplex Ethernet RJ-45 Port

Output
Configurable output signals (0VDC/5VDC) on any of the 4 RJ-45 sensor ports

Power Consumption
1.12 Watt, 0.13A

Status Indictors
LED indication for Power
LED for Network Connectivity
LED for sensor online and threshold status

Components
Manufactured using highly integrated, low power surface mount technology to ensure long term reliability.

Dimensions
Size 8.5″ x 5.43″ x 1.80″
1U Rack Mount Standard
Weight 1.6 Kg

Inputs
x4 RJ-45 ports for connecting AKCess Pro sensors

Operating Environment
Temperature : Min. -35° C – Max.80° C
Humidity : Min. 20% – Max. 80% (Non-Condensing)

ower Requirements
Voltage 7.5 – 9 V / >= 1.2 Amp

Network Interface
Standard 100MB Full Duplex Ethernet RJ-45 Port

Output
Configurable output signals (0VDC/5VDC) on any of the 4 RJ-45 sensor ports

Power Over Ethernet
SP4 PoE is IEEE 802.3af  compliant

Power Consumption
1.12 Watt, 0.13A

Status Indictors
LED indication for Power
LED for Network Connectivity
LED for sensor online and threshold status
